Details
- Alloy disc frame & carbon fork
- Shimano Claris 16-speed drivetrain
- Tektro dual-piston cable disc brakes
- Weinmann XP-24 aluminum rims
- KK disc aluminum hubs
- Kenda Kwest tires
- FSA bottom bracket
- FSA Vero handlebars & cranks
Specs
Frame | New Disc Design, 6061 Aluminum w/Custom Formed Double Butted T/T & D/T, Internal Cable, Flat Mount Disc, Replaceable Derailleur Hanger |
---|---|
Fork | Carbon w/Aluminum Steerer, Flat Mount Disc, Straight Blades |
Rims | Weinmann XP-24 Aluminum Double Wall |
Hubs |
Front: KK Aluminum Disc, QR Rear: KK Aluminum Disc QR, Cassette |
Spokes | 14G Stainless Black, 24x28 |
Tires | Kenda K-193 Kwest Road, 700c x 28 |
Bottom Bracket | FSA Cartridge Bearing |
Crankset | FSA Vero Aluminum, 50x34T, XS:165mm, S-M:170mm, L-XL-175mm |
Shifters | Shimano Claris STI, ST-R2000 |
Front Derailleur | Shimano Claris FD-R2000, 31.8mm |
Rear Derailleur | Shimano Claris RD-R2000SS |
Cassette/Freewheel | Shimano HG200-8, 12-32T, 8-Speed |
Chain | KMC Z8.3 w/Missing Link |
Brakes | Tektro MD-C550 Dual Piston, Flat Mount Road Cable Disc Brake w/160mm Rotors |
Brake Levers | Shimano Claris ST-R2000 |
Handlebars | FSA Vero Compact Bend, 31.8, XS-ML:42cm, L-XL:44cm |
Tape/Grips | Cushion Tape |
Stem | Aluminum 3D Forged, Threadless 4-bolt, 7-degree, 31.8, XS-S:90mm, M-ML:100mm, L-XL:110mm |
Headset | FSA Integrated Cartridge Bearing |
Seatpost | KHS Aluminum Micro-Adjust, 27.2mm |
Saddle | DDK Road Padded |
Pedals | Full Aluminum w/DU Bearing |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Black / Small | 756928928277 | 912160001 | 912160001 |
